型号MODEL(最高出风温度50) |
RCH-2200-50 |
RCH-4500-50 |
RCH-6000-50 |
RCH-7500-50 |
|
型号MODEL(最高出风温度60) |
RCH-2200-60 |
RCH-4500-60 |
RCH-6000-60 |
RCH-7500-60 |
|
除湿能力dehumidify
capacity L/h |
10 |
20 |
26 |
40 |
|
加热能力heating
capacity KW |
6.4 |
12.8 |
17.1 |
21.4 |
|
最高出风温度
The max outlet temperature |
50 / 60
°C |
|
放置环境温度
around temperature |
5 - 40°C |
|
电
源
power source |
1Ø 220V 50HZ |
3Ø 380V 50HZ (or 60HZ) |
|
名义总功率
nominal power Kw |
2.57 |
5.4 |
6.9 |
9.3 |
|
设备控制可选功能
Control function |
送风/除湿/升温/恒温
air supply/ dehumidify/ Warming /
constant temp |
|
干燥作业可选模式
Working pattern |
循环/分段/曲线
[手动(机械式控制)或自动(PLC控制）]
Cycle /time-sharing /subsection /curve
[manual(electromechanical control) or
automatic(PLC control)] |
|
风机风量Air
flow m3/h |
2000 |
3500 |
4500 |
6000 |
|
保护装置
protection device |
电压保护、相序保护、缺相保护、高压保护、低压保护、温度保护、时间延时、过载保护、油温加热及故障显示等装置。
Voltage protector,anti-phase &
lack-phase protector,time delay,the
control and display of high and low
pressure,temperature protector,the
control and display of temperature,the
protectionof over load,the oil
heating,the errors display and so on. |
|
排水口径
Drain inch |
1/2 |
3/4 |
|
主机参考重量
reference Weights kg |
140 |
192 |
280 |
350 |
|
建议干燥间体积
m3
Advice drying room volume |
＜20 |
15-50 |
20-80 |
30-100 |
|
主机参考外型
Reference
dimensions |
高H
mm |
1560 |
1680 |
1760 |
1795 |
|
宽W
mm |
820 |
1150 |
1350 |
1350 |
|
深D
mm |
820 |
1150 |
1250 |
1250 |
|
型号MODEL(最高出风温度50) |
RCH-12000-50 |
RCH-15000-50 |
RCH-22000-50 |
RCH-30000-50 |
|
型号MODEL(最高出风温度60) |
RCH-12000-60 |
RCH-15000-60 |
RCH-22000-60 |
RCH-30000-60 |
|
除湿能力dehumidify
capacity L/h |
52 |
80 |
100 |
160 |
|
加热能力heating
capacity KW |
34.3 |
42.9 |
64.3 |
85.8 |
|
最高出风温度
The max outlet temperature |
50 / 60
°C |
|
放置环境温度
around temperature |
5 - 40°C |
|
电
源
power source |
3Ø 380V 50HZ (or 60HZ) |
|
名义总功率
nominal power Kw |
14.2 |
18 |
26.9 |
36 |
|
设备控制可选功能
Control function |
送风/除湿/升温/恒温
air supply/ dehumidify/ Warming /
constant temp |
|
干燥作业可选模式
Working pattern |
循环/分段/曲线
[手动(机械式控制)或自动(PLC控制）]
Cycle /time-sharing /subsection
/curve [manual(electromechanical
control) or automatic(PLC control)] |
|
风机风量Air
flow m3/h |
9600 |
11000 |
16000 |
22500 |
|
保护装置
protection device |
电压保护、相序保护、缺相保护、高压保护、低压保护、温度保护、时间延时、过载保护、油温加热及故障显示等装置。
Voltage protector,anti-phase &
lack-phase protector,time delay,the
control and display of high and low
pressure,temperature protector,the
control and display of
temperature,the protectionof over
load,the oil heating,the errors
display and so on. |
|
排水口径
Drain inch |
1 |
1-1/2 |
|
主机参考重量
reference Weights kg |
460 |
610 |
880 |
1050 |
|
建议干燥间体积
m3
Advice drying room volume |
45-150 |
60-200 |
90-300 |
120-400 |
|
主机参考外型
Reference
dimensions |
高H
mm |
1950 |
1950 |
2000 |
2000 |
|
宽W
mm |
1850 |
2150 |
2150 |
2150 |
|
深D
mm |
1450 |
1650 |
2000 |
2200 |
注：- 除湿量以进风温度40℃,相对湿度80%条件所得；不同的使用条件，实际除湿量会有差异。
-
保留更改技术或尺寸而不事先通知的权利。
Notice:- Dehumidify capability condition:inlet
temperature is 40℃; relative humidity is 80%;In
different temperatures or different operating
condition,the practical capacity will have
difference.
-
The company keeps the right of revising
technology & dimensions and not informing
customers.
|
|
|
