- to serve the
needs of the equipment or technics low
temperature cooling
each
industry.
-
import medium
and Low Temperature
hermetic or
semi-hermetic compressor.
- packaged
configuration,has ice water pump and stainless
steel water tank inside.
- relay or
microcomputer or plc control.
- temperature
control range:-40℃- +5℃.
- regrigeration
power:3HP-40HP.
- water-cooled
or air-cooled.
model
water
cooled
WP-04D
WP-06D
WP-08D
WP-10D
WP-15D
WP-20D
WP-30D
WP-40D
air
cooled
RP-3D
RP-5D
RP-8D
RP-10D
RP-15D
RP-20D
RP-30D
RP-40D
0 - -15℃ type refrigerated capacity
capacity
-5/40℃*
Kw
6.9
10.0
14.2
17.1
28.2
34.2
56.4
68.4
kcal/h
5934
8600
12212
14706
24252
29412
48504
58824
capacity
-10/40℃
Kw
5.6
7.9
11.2
13.3
22.3
26.6
44.6
53.2
kcal/h
4816
6794
9632
11438
19178
22876
38356
45752
capacity
-15/40℃
Kw
4.3
6.0
8.5
10.2
17.2
20.4
34.4
40.8
kcal/h
3698
5160
7310
8772
14792
17544
29584
35088
capacity
-20/40℃
Kw
3.2
4.4
6.3
7.5
13.1
15.0
26.2
30.0
kcal/h
2752
3784
5418
6450
11266
12900
22532
25800
-15 - - 40℃ type refrigerated
capacity
capacity
-25/40℃
Kw
2.8
5.7
9.0
11.7
17.4
23.4
34.8
46.8
kcal/h
2408
4902
7740
10062
14964
20124
29928
40248
capacity
-30/40℃
Kw
2.2
4.4
6.6
8.8
13.2
17.6
26.4
35.2
kcal/h
1892
3784
5676
7568
11352
15136
22704
30272
capacity
-35/40℃
Kw
1.6
3.2
4.6
6.3
9.5
12.6
19.0
25.2
kcal/h
1376
2752
3956
5418
8170
10836
16340
21672
capacity
-40/40℃
Kw
1.1
2.2
3.4
4.8
7.0
9.6
14.0
19.2
kcal/h
946
1892
2924
4128
6020
8256
12040
16512
capacity
-45/40℃
Kw
0.56
1.3
1.7
2.5
3.8
5.0
7.6
10.0
kcal/h
481
1118
1462
2150
3268
4300
6536
8600
can
control temp
°C
-40℃
- +40℃（order
please indicate the lowest temp）
power
source
3Ø
380V 50HZ（or select 60HZ）
compressor
kw
2.25
3.75
6
7.5
11.25
15
22.5
30
evaporator
water
tank type (or select
shell pipe)
condenser
water
cooled
shell
and tube or shell pipe
air
cooled
cross-finned
rubes
refrigerant
R-22/R502(or select
R404A)
in/out
pipe inch
1
1
1-1/4
1-1/2
2
2-1/2
2-1/2
3
ice
water pump kw
0.37
0.37
0.37
0.75
1.5
2.25
2.25
3.75
protection
device
time
delay,the protection of water
shortage,the control and display of
high and low pressure,the control and
display of temperature,the
protectionof over load,the oil
heating,the errors display and so on.
outside
dimensions
H mm
990
1010
1010
1150
1190
1200
1190
1250
1250
1280
1250
1280
1400
1800
1480
1880
W mm
550
495
580
540
540
830
560
830
620
850
990
850
1000
1000
1100
1700
D mm
770
970
880
1000
1200
1550
1200
1560
1450
1850
1450
2000
1750
2200
2050
2200
*
vaporize temperature is
-5/-10/-15/-20/-25/-30/-35/-40/-45℃,condenster
temperature is 40℃.
- order
please indicate the lowest temp.
- other
specification according to demand.
-
reserves the right to modify the details
shown here in without prior notification.
